Artikelnummer | G101STN01.G |
Marke | AUO |
Größe | 10.1 |
Anwendung | Industrial |
Auflösung | 1024×600 |
Komposition | a-Si TFT-LCD , LCM |
Helligkeit | |
CR | 500:1 |
Farben | 262K/16.7M |
Hintergrundbeleuchtung | WLED |
Schnittstelle | |
Panel-Marke | AUO |
Panelgröße | 10.1" |
Auflösung | 1024(RGB)×600, WSVGA, 117PPI |
Anzeigebereich | 222.72(W)×125.28(H) mm |
Umrissgröße | 235(W)×143(H) ×5.2(D) mm |
Helligkeit | 250 cd/m² (Typ.) |
Blickwinkel | 70/70/60/60 (Typ.)(CR≥10) |
beste Aussicht auf | - |
Farben anzeigen | 262K/16.7M 45% NTSC |
Frequenz | 60Hz |
Gewicht | 180g (Typ.) |
Panel-Modell | G101STN01.G (AUO10D2) |
Plattentyp | a-Si TFT-LCD , LCM |
Pixelformat | RGB Vertical Stripe |
Blendenöffnung | 226.34(W)×128.1(H) mm |
Oberfläche | Antiglare, Hard coating (3H) |
Kontrastverhältnis | 500:1 (Typ.) (TM) |
Anzeigemodus | TN, Normally White, Transmissive |
Reaktionszeit | 7/9 (Typ.)(Tr/Td) |
Lampentyp | WLED , 15K hours , With LED Driver |
Touch-Screen | Without |
Anwendung | Industrial |
