| Artikelnummer | DLC0500HZG-T-8 |
| Marke | Other |
| Größe | 5.0 |
| Anwendung | PND |
| Auflösung | 800×480 |
| Komposition | LCM |
| Helligkeit | 640 |
| CR | 500:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | DLC |
| Panel-Modell | DLC0500HZG-T-8 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.0 inch |
| Auflösung | 800(RGB)×480 , WVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 108×64.8 mm |
| Umriss | 120.7×75.8×4.5 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 640 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193150% |
| Reaktionszeit | 20 (Typ.)(Tr+Td) |
| Blickwinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 10S2PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 8-bit), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PND |
