| Artikelnummer | WEO009664AB |
| Marke | Winstar |
| Größe | 0.95 |
| Anwendung | Wearable MP3 PMP |
| Auflösung | 96×64 |
| Komposition | PM-OLED, OLED |
| Helligkeit | |
| CR | |
| Farben | Mono(Blue) |
| Hintergrundbeleuchtung | self |
| Schnittstelle | 8-bit |
| Marke | Winstar |
| Modell | WEO009664AB |
| diagonale Größe | 0.95 inch |
| Typ | PM-OLED, OLED |
| Pixelformat | 96×64 121PPI |
| Aufbau | Rectangle |
| aktiver Bereich | 19.946(H)×13.418(V) mm |
| Umriss dunkel. | 24.9(H)×22.95(V) ×1.95(D) mm |
| Lünettenbereich | 21.953(H)×15.424(V) mm |
| Behandlung | - |
| Blickrichtung | Symmetry |
| Reaktionszeit | - |
| Blickwinkel | - |
| Betriebsart | - |
| Unterstützungsfarbe | Mono(Blue) |
| Lichtquelle | self |
| Gewicht | - |
| designed für | Wearable MP3 PMP |
| Bildrate | - |
| Touch-Panel | Without |
| D-IC-Detail | COG Built-in SSD1305Z |
| Oberflächentyp | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 25 pins FPC |
| Stromversorgung | 3.0V (Typ.) |
| Umfeld | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
