| Artikelnummer | TM080VDSP01 |
| Marke | Tianma |
| Größe | 8.0 |
| Anwendung | PAD |
| Auflösung | 1200×1920 |
| Komposition | LCM |
| Helligkeit | 390 |
| CR | 900:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | TIANMA |
| Panel-Modell | TM080VDSP01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 8.0 inch |
| Auflösung | 1200(RGB)×1920 , WUXGA |
| Anzeigemodus | SFT, Normally Black, Transmissive |
| aktiver Bereich | 107.64×172.224 mm |
| Umriss | 114.6×184.1×2.3 mm |
| Oberfläche | |
| Helligkeit | 390 cd/m² (Typ.) |
| Kontrastverhältnis | 900:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193160% |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 7S3PWLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 31 pins |
| Eingangsspannung | 3.3/10.0/18.0/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| Anwendung | PAD |
