| Artikelnummer | TD036THEA1 |
| Marke | TPO |
| Größe | 3.6 |
| Anwendung | |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 280 |
| CR | 300:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Serial RGB |
| Panel-Marke | Toppoly |
| Panel-Modell | TD036THEA1 |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 3.6 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 72.96×54.72 mm |
| Umriss | 80.2×66.3 mm |
| Oberfläche | Hard coating (3H) |
| Helligkeit | 280 cd/m² (Typ.) |
| Kontrastverhältnis | 300:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 13/22 (Typ.)(Tr/Td) |
| Blickwinkel | 50/20/40/40 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 3S2PWLED |
| Signalschnittstelle | Serial RGB (8-bit) + SPI, CCIR601, 39 pins |
