| Artikelnummer | T240XW01 V0 |
| Marke | AUO |
| Größe | 24.0 |
| Anwendung | LCTV |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 320 |
| CR | 2500:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | AUO |
| Panel-Modell | T240XW01 V0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 24.0 inch |
| Auflösung | 1366×768(RGB) , WXGA |
| Anzeigemodus | VA, Normally Black, Transmissive |
| aktiver Bereich | 531.72×298.94 mm |
| Umriss | 580×347.5 mm |
| Oberfläche | Antiglare (Haze 11%), Hard coating (3H) |
| Helligkeit | 320 cd/m² (Typ.) |
| Kontrastverhältnis | 2500:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 6.5 (Typ.)(Tr+Td) |
| Blickwinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 3 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
