| Artikelnummer | P645HW03 V0 |
| Marke | AUO |
| Größe | 65 |
| Anwendung | PID |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 700 |
| CR | 4000:1 |
| Farben | 1.07B |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | AUO |
| Panel-Modell | P645HW03 V0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 65 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | AMVA3, Normally Black, Transmissive |
| aktiver Bereich | 1428.48×803.52 mm |
| Umriss | 1482.4×862 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 700 cd/m² (Typ.) |
| Kontrastverhältnis | 4000:1 (Typ.) |
| Farben anzeigen | 1.07B (10-bit), CIE193172% |
| Reaktionszeit | 15/8 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | CCFLEmbedded (Inverter) |
| Signalschnittstelle | LVDS (2 ch, 10-bit), 51 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | PID |
