| Artikelnummer | P50AD4 |
| Marke | E Ink |
| Größe | 5.0 |
| Anwendung | |
| Auflösung | 320×234 |
| Komposition | LCM |
| Helligkeit | 320 |
| CR | 120:1 |
| Farben | Full color |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Analog |
| Panel-Marke | PVI |
| Panel-Modell | P50AD4 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.0 inch |
| Auflösung | 320(RGB)×234 |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 102.6×73.9 mm |
| Umriss | 126.9×92.7×13.2 mm |
| Oberfläche | |
| Helligkeit | 320 cd/m² (Typ.) |
| Kontrastverhältnis | 120:1 (Typ.) |
| Farben anzeigen | Full color |
| Reaktionszeit | 30/50 (Max.)(Tr/Td) |
| Blickwinkel | 55/55/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | Analog RGB, 20 pins |
| Eingangsspannung | 5/14/20/-5V (Typ.)(VDD/VSH/VGH/VGL) |
