| Artikelnummer | NL6448BC33-64D |
| Marke | NLT |
| Größe | 10.4 |
| Anwendung | IA |
| Auflösung | 640×480 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 600:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | TTL |
| Panel-Marke | NEC |
| Panel-Modell | NL6448BC33-64D |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 10.4 inch |
| Auflösung | 640(RGB)×480 , VGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 211.2×158.4 mm |
| Umriss | 243×185.1×11 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193140% |
| Reaktionszeit | 6/25 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/55 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 2 pcsCCFLWithout Driver |
| Signalschnittstelle | CMOS (1 ch, 6-bit), 31 pins |
| Eingangsspannung | 3.3/5.0V (Typ.) |
| Anwendung | IA |
| NL6448BC18-03F | NLT | 5.7 | 640×480 |
| NL6448BC20-20 | NLT | 6.5 | 640×480 |
| NL6448BC20-30F | NLT | 6.5 | 640×480 |
| NL6448BC20-35D | NLT | 6.5 | 640×480 |
| NL6448BC26-01 | NLT | 8.4 | 640×480 |
| NL6448BC26-09 | NLT | 8.4 | 640×480 |
| NL6448BC33-54 | NLT | 10.4 | 640×480 |
| NL6448BC33-59D | NLT | 10.4 | 640×480 |
| NL6448BC33-63D | NLT | 10.4 | 640×480 |
| NL6448BC33-70D | NLT | 10.4 | 640×480 |
| A101AIE40L0 | Aptus | 10.1 | 1280×720 |
| AA070MC01 | Mitsubishi | 7.0 | 800×480 |
| G150XG01 V3 | AUO | 15.0 | 1024×768 |
| G190SF01 V0 | AUO | 19.0 | 1680×342 |
| KCB104VG2CG-G20 | Kyocera | 10.4 | 640×480 |
| LQ025Q3DW01 | SHARP | 2.5 | 320×240 |
| LQ104V1DG61 | SHARP | 10.4 | 640×480 |
| LQ190E1LW42 | SHARP | 19.0 | 1280×1024 |
| LTM04C380K | TOSHIBA | 4.0 | 640×480 |
| TX38D25VM0CAA | KOE | 14.9 | 1280×242 |
