| Artikelnummer | NL204153BM21-05A |
| Marke | NLT |
| Größe | 21.3 |
| Anwendung | MD |
| Auflösung | 2048×1536 |
| Komposition | LCM |
| Helligkeit | |
| CR | |
| Farben | Grayscale |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | NEC |
| Panel-Modell | NL204153BM21-05A |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 21.3 inch |
| Auflösung | 2048(LCR)×1536 , QXGA |
| Anzeigemodus | SA-SFT, Normally Black, Transmissive |
| aktiver Bereich | 433.152×324.864 mm |
| Oberfläche | |
| Helligkeit | |
| Kontrastverhältnis | |
| Farben anzeigen | Grayscale (8-bit) |
| Reaktionszeit | |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (4 ch, 8-bit) |
| Anwendung | MD |
