| Artikelnummer | NL160120AC27-32B |
| Marke | NLT |
| Größe | 21.3 |
| Anwendung | MD |
| Auflösung | 1600×1200 |
| Komposition | LCM |
| Helligkeit | 760 |
| CR | 1200:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | NEC |
| Panel-Modell | NL160120AC27-32B |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 21.3 inch |
| Auflösung | 1600(RGB)×1200 , UXGA |
| Anzeigemodus | UA-SFT, Normally Black, Transmissive |
| aktiver Bereich | 432×324 mm |
| Umriss | 457×350×23 mm |
| Oberfläche | Antiglare, Hard coating (2H) |
| Helligkeit | 760 cd/m² (Typ.) |
| Kontrastverhältnis | 1200:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 20/20 (Typ.)(Tr/Td) |
| Blickwinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 30 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | MD |
