| Artikelnummer | N173O6-L02 |
| Marke | Innolux |
| Größe | 17.3 |
| Anwendung | NBPC |
| Auflösung | 1600×900 |
| Komposition | LCM |
| Helligkeit | 220 |
| CR | 600:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | CMO |
| Panel-Modell | N173O6-L02 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 17.3 inch |
| Auflösung | 1600(RGB)×900 , HD+ |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 382.08×214.92 mm |
| Umriss | 398.1×232.8×5.8 mm |
| Formstil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Oberfläche | Glare (Haze 0%), Hard coating (3H) |
| Helligkeit | 220 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 2/6 (Typ.)(Tr/Td) |
| Blickwinkel | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 9S8PWLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (2 ch, 6-bit), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NBPC |
| B173HW02 V1 | AUO | 17.3 | 1920×1080 |
| B173RW01 V3 | AUO | 17.3 | 1600×900 |
| LP173WD1-TLN2 | LG Display | 17.3 | 1600×900 |
| LP173WD1-TLN4 | LG Display | 17.3 | 1600×900 |
| LP173WF1-TLA1 | LG Display | 17.3 | 1920×1080 |
| LP173WF1-TLA2 | LG Display | 17.3 | 1920×1080 |
| LP173WF1-TLB2 | LG Display | 17.3 | 1920×1080 |
| LTN173KT01-D01 | Samsung | 17.3 | 1600×900 |
| N173FGE-E23 | Innolux | 17.3 | 1600×900 |
| N173O6-L02 | Innolux | 17.3 | 1600×900 |
| B121EW03 V7 | AUO | 12.1 | 1280×800 |
| LM12S029 | SHARP | 12.1 | 800×600 |
| LP140WH2-TLF3 | LG Display | 14.0 | 1366×768 |
| LP156WH3-TPS2 | LG Display | 15.6 | 1366×768 |
| LP156WH8-TLA2 | LG Display | 15.6 | 1366×768 |
| LQ133T1JW02 | SHARP | 13.3 | 2560×1440 |
| LT121SS-124 | Samsung | 12.1 | 800×600 |
| N156B6-L01 | Innolux | 15.6 | 1366×768 |
| NL8060BC31-13A | NLT | 12.1 | 800×600 |
| NT156FHM-N41 | BOE | 15.6 | 1920×1080 |
