| Artikelnummer | MT3151A05-2 |
| Marke | CSOT |
| Größe | 31.5 |
| Anwendung | LCTV |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 3000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | CSOT |
| Panel-Modell | MT3151A05-2 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 31.5 inch |
| Auflösung | 1366×768(RGB) , WXGA |
| Anzeigemodus | HVA, Normally Black, Transmissive |
| aktiver Bereich | 697.685×392.256 mm |
| Umriss | 735.4×433 mm |
| Oberfläche | Antiglare (Haze 2%), Hard coating (3H) |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 3000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193162% |
| Reaktionszeit | 6.5 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
| AX080A080G | KOE | 31.5 | 1366×768 |
| LC320EXN-SEA1 | LG Display | 31.5 | 1366×768 |
| LC320WUD-SCA1 | LG Display | 31.5 | 1920×1080 |
| LTA320AP12 | Samsung | 31.5 | 1366×768 |
| LTA320HN04-W | Samsung | 31.5 | 1920×1080 |
| MT3151A05-2 | CSOT | 31.5 | 1366×768 |
| T315HW05 V3 | AUO | 31.5 | 1920×1080 |
| V315B3-L04 | Innolux | 31.5 | 1366×768 |
| V315B5-L06 | Innolux | 31.5 | 1366×768 |
| V315B6-L03 | Innolux | 31.5 | 1366×768 |
| LC420EUF-PGF1 | LG Display | 42 | 1920×1080 |
| LC420EUN-FEF1 | LG Display | 42 | 1920×1080 |
| LC550EQE-PGF2 | LG Display | 55 | 3840×2160 |
| MT2751A01-1 | CSOT | 27.5 | 1366×768 |
| T315HW07 V2 | AUO | 31.5 | 1920×1080 |
| T460HW02 V1 | AUO | 46 | 1920×1080 |
| T550QVD01.0 | AUO | 55 | 3840×2160 |
| T645HW05 V0 | AUO | 65 | 1920×1080 |
| V420H1-LH4 | Innolux | 42 | 1920×1080 |
| V420H2-LN1 | Innolux | 42 | 1920×1080 |
