| Artikelnummer | M215HJJ-P02 |
| Marke | Innolux |
| Größe | 21.5 |
| Anwendung | DMPC |
| Auflösung | 1920×1080 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 3000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | LVDS |
| Panel-Marke | INNOLUX |
| Panel-Modell | M215HJJ-P02 |
| Plattentyp | a-Si TFT-LCD , CELL |
| Panelgröße | 21.5 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | MVA, Normally Black, Transmissive |
| aktiver Bereich | 476.064×267.786 mm |
| Umriss | 487.664×279.286 mm |
| Oberfläche | Antiglare (Haze 25%), Hard coating (3H) |
| Glastiefe | 0.50+0.50 mm |
| Durchlässigkeit | 4.46% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 3000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 20/5 (Typ.)(Tr/Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥20)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 30 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | DMPC |
