| Artikelnummer | LV057JC111 |
| Marke | Innolux |
| Größe | 5.7 |
| Anwendung | GM |
| Auflösung | 640×480 |
| Komposition | LCM |
| Helligkeit | 350 |
| CR | 350:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | ChiHsin |
| Panel-Modell | LV057JC111 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.7 inch |
| Auflösung | 640(RGB)×480 , VGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 115.2×86.4 mm |
| Umriss | 125×98.8×5.84 mm |
| Oberfläche | Antiglare (Haze 25%), Hard coating |
| Helligkeit | 350 cd/m² (Typ.) |
| Kontrastverhältnis | 350:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193150% |
| Reaktionszeit | 15/35 (Typ.)(Tr/Td) |
| Blickwinkel | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 7S3PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| Eingangsspannung | 3.3/8.4/15.0/-10.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| Anwendung | GM |
