| Artikelnummer | AMS495QA04 |
| Marke | Samsung |
| Größe | 5.0 |
| Anwendung | GM |
| Auflösung | 960×544 |
| Komposition | OLED |
| Helligkeit | 140 |
| CR | 6500:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | self |
| Schnittstelle | MIPI |
| Panel-Marke | SAMSUNG |
| Panel-Modell | AMS495QA04 |
| Plattentyp | AM-OLED , OLED |
| Panelgröße | 5.0 inch |
| Auflösung | 960(RGB)×544 , qHD |
| aktiver Bereich | 109.44×62.02 mm |
| Umriss | 116.54×73.92 mm |
| Oberfläche | |
| Helligkeit | 140 cd/m² (Typ.) |
| Kontrastverhältnis | 6500 : 1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE1931100% |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥200)(L/R/U/D) |
| Frequenz | 60Hz |
| Treiber-IC | Built-in D53E6EA8933 |
| Signalschnittstelle | MIPI (2 data lanes), 40 pins |
| Eingangsspannung | 1.8/3.0/V (Typ.)(VDD/VCI/ELVDD/ELVSS) |
| Anwendung | GM |
