| Artikelnummer | LTY400WS-L02 |
| Marke | Samsung |
| Größe | 40 |
| Anwendung | LCTV |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 530 |
| CR | 1200:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | S-LCD |
| Panel-Modell | LTY400WS-L02 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 40 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | S-PVA, Normally Black, Transmissive |
| aktiver Bereich | 885.168×497.664 mm |
| Umriss | 952×551×52 mm |
| Oberfläche | Antiglare (Haze 44%), Hard coating (3H) |
| Helligkeit | 530 cd/m² (Typ.) |
| Kontrastverhältnis | 1200:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 10/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 20 pcsCCFLEmbedded (Inverter) |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 41 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | LCTV |
