| Artikelnummer | LTM240CL04 |
| Marke | Samsung |
| Größe | 24.0 |
| Anwendung | DMPC |
| Auflösung | 1920×1200 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | SAMSUNG |
| Panel-Modell | LTM240CL04 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 24.0 inch |
| Auflösung | 1920(RGB)×1200 , WUXGA |
| Anzeigemodus | PLS, Normally Black, Transmissive |
| aktiver Bereich | 518.4×324 mm |
| Umriss | 546.4×350×11.2 mm |
| Oberfläche | Antiglare (Haze 25%), Hard coating (3H) |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Reaktionszeit | 15 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 13S3PWLEDWithout Driver |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 30 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | DMPC |
