| Artikelnummer | M240UP01 V0 |
| Marke | AUO |
| Größe | 24.0 |
| Anwendung | DMPC |
| Auflösung | 1920×1200 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Analog + Digital |
| Panel-Marke | AUO |
| Panel-Modell | M240UP01 V0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 24.0 inch |
| Auflösung | 1920(RGB)×1200 , WUXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 518.4×324 mm |
| Umriss | 546.4×352 mm |
| Oberfläche | Antiglare |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Hi-FRC) |
| Reaktionszeit | 3.8/1.2 (Typ.)(Tr/Td); 2 (Typ.)(G to G) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4 pcsCCFLWithout Driver |
| Signalschnittstelle | Analog RGB + DVI-D, 70 pins |
| Anwendung | DMPC |
