| Artikelnummer | LTD121EXFV |
| Marke | TOSHIBA |
| Größe | 12.1 |
| Anwendung | NBPC |
| Auflösung | 1280×768 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 600:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | Toshiba Matsushita |
| Panel-Modell | LTD121EXFV 1 Compatible model |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 12.1 inch |
| Auflösung | 1280(RGB)×768 , WXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 263.04×157.824 mm |
| Umriss | 275×173.5×5.2 mm |
| Formstil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Oberfläche | Glare (Haze 0%), Hard coating (2H) |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 50 (Max.)(Tr+Td) |
| Blickwinkel | 30/30/10/20 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 20 pins |
| Eingangsspannung | 3.3V (Typ.) |
| rohs: | |
| Anwendung | NBPC |
| LTD121C30S | TOSHIBA | 12.1 | 800×600 |
| LTD121C32S | TOSHIBA | 12.1 | 800×600 |
| LTD121EA4XY | TOSHIBA | 12.1 | 1024×768 |
| LTD121EC5S | TOSHIBA | 12.1 | 1024×768 |
| LTD121EXFV | TOSHIBA | 12.1 | 1280×768 |
| LTD121EXPV | TOSHIBA | 12.1 | 1280×800 |
| LTD121EXSF | TOSHIBA | 12.1 | 1280×800 |
| LTD121KM7K | TOSHIBA | 12.1 | 1400×1050 |
| LTD121KX5V | TOSHIBA | 12.1 | 1280×800 |
| LTD121LA3SG-201 | TOSHIBA | 12.1 | 1024×768 |
| B133XW07 V0 | AUO | 13.3 | 1366×768 |
| B156XW01 V0 | AUO | 15.6 | 1366×768 |
| LP140WH4-TLP1 | LG Display | 14.0 | 1366×768 |
| LP141WX5-TLA1 | LG Display | 14.1 | 1280×800 |
| LT121DEE3P00 | TOSHIBA | 12.1 | 1024×768 |
| LTN133AT05-001 | Samsung | 13.3 | 1280×800 |
| LTN156AT02-D04 | Samsung | 15.6 | 1366×768 |
| N140B6-L06 | Innolux | 14.0 | 1366×768 |
| N156BGE-L41 | Innolux | 15.6 | 1366×768 |
| NV156FHM-N43 | BOE | 15.6 | 1920×1080 |
