| Artikelnummer | LQ084V1DG21E |
| Marke | SHARP |
| Größe | 8.4 |
| Anwendung | IA |
| Auflösung | 640×480 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 250:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | TTL |
| Panel-Marke | SHARP |
| Panel-Modell | LQ084V1DG21E |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 8.4 inch |
| Auflösung | 640(RGB)×480 , VGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 170.88×129.6 mm |
| Umriss | 216×152.4 mm |
| Oberfläche | |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 250:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 20/40 (Typ.)(Tr/Td) |
| Blickwinkel | 55/55/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 1 pcsCCFL |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 31 pins |
| rohs: | |
| Anwendung | IA |
