| Artikelnummer | LP154W02-TL10 |
| Marke | LG Display |
| Größe | 15.4 |
| Anwendung | NBPC |
| Auflösung | 1680×1050 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | LG.Philips LCD |
| Panel-Modell | LP154W02-TL10 9 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.4 inch |
| Auflösung | 1680(RGB)×1050 , WSXGA+ |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 331.38×207.11 mm |
| Umriss | 344×222×6.5 mm |
| Formstil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Oberfläche | Antiglare, Hard coating (2H), Antireflection |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193145% |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 65/65/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (2 ch, 6-bit), 30 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NBPC |
| LP154W01-TLA2 | LG Display | 15.4 | 1280×800 |
| LP154W01-TLAE | LG Display | 15.4 | 1280×800 |
| LP154W02-B1K6 | LG Display | 15.4 | 1680×1050 |
| LP154W02-TL06 | LG Display | 15.4 | 1680×1050 |
| LP154W02-TL10 | LG Display | 15.4 | 1680×1050 |
| LP154WE2-TLA3 | LG Display | 15.4 | 1680×1050 |
| LP154WE2-TLA7 | LG Display | 15.4 | 1680×1050 |
| LP154WE3-TLB1 | LG Display | 15.4 | 1680×1050 |
| LP154WP3-TLA3 | LG Display | 15.4 | 1440×900 |
| LP154WX7-TLB3 | LG Display | 15.4 | 1280×800 |
| HT14P12-101 | HYDIS | 14.1 | 1400×1050 |
| LP104S2 | LG Display | 10.4 | 800×600 |
| LP140WH2-TLA2 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TPS1 | LG Display | 14.0 | 1366×768 |
| LP141WX1-TL04 | LG Display | 14.1 | 1280×800 |
| LP156WH2-TPB1 | LG Display | 15.6 | 1366×768 |
| LTD133KX2S | TOSHIBA | 13.3 | 1280×800 |
| LTN154X3-L0D-G | Samsung | 15.4 | 1280×800 |
| NL8060BC26-15 | NLT | 10.4 | 800×600 |
| TM150SP-02L01 | SANYO | 15.0 | 1400×1050 |
