| Artikelnummer | LP125WH2-TLD1 |
| Marke | LG Display |
| Größe | 12.5 |
| Anwendung | NBPC |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 200:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | LG Display |
| Panel-Modell | LP125WH2-TLD1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 12.5 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 276.615×155.52 mm |
| Umriss | 290.5×179.5×3.6 mm |
| Formstil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| Oberfläche | Antiglare |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 200:1 (Min.) |
| Farben anzeigen | 262K (6-bit), CIE193145% |
| Reaktionszeit | 16 (Typ.)(Tr+Td) |
| Blickwinkel | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NBPC |
| LP125WF1-SPA2 | LG Display | 12.5 | 1920×1080 |
| LP125WF1-SPD1 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB1 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB3 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLT2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPR1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLE1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLFA | LG Display | 12.5 | 1366×768 |
| B140XW02 V0 | AUO | 14.0 | 1366×768 |
| LP133X7-P2IB | LG Display | 13.3 | 1024×768 |
| LP140WF1-SPK1 | LG Display | 14.0 | 1920×1080 |
| LP141WX1-TLE1 | LG Display | 14.1 | 1280×800 |
| LTD111EXCA | TOSHIBA | 11.1 | 1366×768 |
| LTN133AT23-C01 | Samsung | 13.3 | 1366×768 |
| LTN141AT05-001 | Samsung | 14.1 | 1280×800 |
| LTN150XG-L04 | Samsung | 15.0 | 1024×768 |
| LTN160AT05-001 | Samsung | 16.0 | 1366×768 |
| N154Z1-L02 | Innolux | 15.4 | 1680×1050 |
