| Artikelnummer | LP097X02-SLQA |
| Marke | LG Display |
| Größe | 9.7 |
| Anwendung | PAD |
| Auflösung | 1024×768 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 600:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | LG Display |
| Panel-Modell | LP097X02-SLQA 10 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 9.7 inch |
| Auflösung | 1024(RGB)×768 , XGA |
| Anzeigemodus | S-IPS, Normally Black, Transmissive |
| aktiver Bereich | 196.608×147.456 mm |
| Umriss | 210.35×166.25×5.45 mm |
| Oberfläche | Glare (Haze 0%), Hard coating (3H) |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6S6PWLEDWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 30 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PAD |
