| Artikelnummer | LB070WV3-SD01 |
| Marke | LG Display |
| Größe | 7.0 |
| Anwendung | CNS |
| Auflösung | 800×480 |
| Komposition | LCM |
| Helligkeit | 470 |
| CR | 900:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | LG Display |
| Panel-Modell | LB070WV3-SD01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 7.0 inch |
| Auflösung | 800(RGB)×480 , WVGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 152.4×91.44 mm |
| Umriss | 170×109.6×29.4 mm |
| Oberfläche | Antiglare, Antireflection |
| Helligkeit | 470 cd/m² (Typ.) |
| Kontrastverhältnis | 900:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193160% |
| Reaktionszeit | 15/14 (Typ.)(Tr/Td) |
| Blickwinkel | 70/70/30/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 8S3PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | CNS |
