| Artikelnummer | KCB084SV1AC-G40 |
| Marke | Kyocera |
| Größe | 8.4 |
| Anwendung | IA |
| Auflösung | 800×600 |
| Komposition | LCM |
| Helligkeit | |
| CR | 30:1 |
| Farben | Color |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Parallel Data |
| Panel-Marke | Kyocera |
| Panel-Modell | KCB084SV1AC-G40 |
| Plattentyp | CSTN-LCD , LCM |
| Panelgröße | 8.4 inch |
| Auflösung | 800(RGB)×600 , SVGA |
| Anzeigemodus | STN, Normally Black, Transmissive |
| aktiver Bereich | 170.4×127.8 mm |
| Umriss | 205.1×145 mm |
| Oberfläche | |
| Helligkeit | |
| Kontrastverhältnis | 30:1 (Typ.) |
| Farben anzeigen | Color |
| Reaktionszeit | 300/250 (Typ.)(Tr/Td) |
| Blickwinkel | 55/50/35/20 (Typ.)(CR≥2)(L/R/U/D) |
| Lampentyp | 1 pcsCCFL |
| Signalschnittstelle | Parallel Data (8-bit), 31 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
| KCB084SV1AC-G40 | Kyocera | 8.4 | 800×600 |
| LAJ084T001A | TPO | 8.4 | 800×600 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LQ9D001 | SHARP | 8.4 | 640×480 |
| LTM08C356F | TOSHIBA | 8.4 | 800×600 |
| NL10276BC16-06D | NLT | 8.4 | 1024×768 |
| NL6448BC26-01 | NLT | 8.4 | 640×480 |
| NL6448BC26-17 | NLT | 8.4 | 640×480 |
| NL6448BC26-25 | NLT | 8.4 | 640×480 |
| TM084SDHG02 | Tianma | 8.4 | 800×600 |
| AM-800600M3TNQW-01H-F | AMPIRE | 8.4 | 800×600 |
| DMF-51043NFU-FW-1 | Kyocera | 9.4 | 640×480 |
| KCG075VG2BB-G00 | Kyocera | 7.5 | 640×480 |
| LB104S01-TL02 | LG Display | 10.4 | 800×600 |
| LQ10DH11 | SHARP | 10.4 | 640×480 |
| LTD121C33S | TOSHIBA | 12.1 | 800×600 |
| LTD121C33U | TOSHIBA | 12.1 | 800×600 |
| PD121XL3 | E Ink | 12.1 | 1024×768 |
| SH320240C | Other | 5.7 | 320×240 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
