| Artikelnummer | G150XTN06.0 |
| Marke | AUO |
| Größe | 15.0 |
| Anwendung | IA |
| Auflösung | 1024×768 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 800:1 |
| Farben | 262K/16.2M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | AUO |
| Panel-Modell | G150XTN06.0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.0 inch |
| Auflösung | 1024(RGB)×768 , XGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 304.128×228.096 mm |
| Umriss | 326.5×253.5×12.5 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 262K/16.2M (6-bit / 6-bit + FRC), CIE193160% |
| Reaktionszeit | 5.7/2.3 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/70/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (1 ch, 6/8-bit), 20 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
| G150X1-L01 | Innolux | 15.0 | 1024×768 |
| G150X1-L02 | Innolux | 15.0 | 1024×768 |
| G150XG01 V0 | AUO | 15.0 | 1024×768 |
| G150XG01 V4 | AUO | 15.0 | 1024×768 |
| G150XG03 V4 | AUO | 15.0 | 1024×768 |
| G150XGE-L06 | Innolux | 15.0 | 1024×768 |
| G150XTN01.0 | AUO | 15.0 | 1024×768 |
| G150XTN03.2 | AUO | 15.0 | 1024×768 |
| G150XTN06.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| AC150XA01 | Mitsubishi | 15.0 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| CLAA104XA12BW | CPT | 10.4 | 1024×768 |
| HM150X01-101 | BOE | 15.0 | 1024×768 |
| LQ057V3LG11 | SHARP | 5.7 | 640×480 |
| LQ104S1LG81 | SHARP | 10.4 | 800×600 |
| LQ9D03B | SHARP | 8.4 | 640×480 |
| SG12832A | Other | 1.9 | 128×32 |
| TCG058QVLAA-G00 | Kyocera | 5.8 | 320×240 |
| UG-9664HSWAG01 | WiseChip | 0.95 | 96×64 |
