| Artikelnummer | G104X1-L02 |
| Marke | Innolux |
| Größe | 10.4 |
| Anwendung | GM |
| Auflösung | 1024×768 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | 1200:1 |
| Farben | 16.2M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | CMO |
| Panel-Modell | G104X1-L02 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 10.4 inch |
| Auflösung | 1024(RGB)×768 , XGA |
| Anzeigemodus | Super MVA, Normally Black, Transmissive |
| aktiver Bereich | 210.4×157.8 mm |
| Umriss | 225.5×176.3×10.67 mm |
| Oberfläche | Glare (Haze 0%), Hard coating (3H) |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 1200:1 (Typ.) |
| Farben anzeigen | 16.2M (6-bit + FRC), CIE193157% |
| Reaktionszeit | 14/11 (Typ.)(Tr/Td) |
| Blickwinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 2 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | GM |
