| Artikelnummer | EL640.480-A4 SBS |
| Marke | PLANAR |
| Größe | 10.4 |
| Anwendung | IA |
| Auflösung | 640×480 |
| Komposition | EL |
| Helligkeit | 55 |
| CR | |
| Farben | Grayscale |
| Hintergrundbeleuchtung | self |
| Schnittstelle | Parallel Data |
| Panel-Marke | PLANAR |
| Panel-Modell | EL640.480-A4 SBS |
| Plattentyp | EL , EL |
| Panelgröße | 10.4 inch |
| Auflösung | 640×480 , VGA |
| aktiver Bereich | 211.1×158.3 mm |
| Umriss | 263×192 mm |
| Oberfläche | |
| Helligkeit | 55 cd/m² (Typ.) |
| Kontrastverhältnis | |
| Farben anzeigen | Grayscale (4-bit) |
| Blickwinkel | |
| Frequenz | 60Hz |
| Signalschnittstelle | Parallel Data (4-bit), 40 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | IA |
