| Artikelnummer | CLAA156WA11A |
| Marke | CPT |
| Größe | 15.6 |
| Anwendung | NBPC |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 220 |
| CR | 600:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | CPT |
| Panel-Modell | CLAA156WA11A 16 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.6 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 344.232×193.536 mm |
| Umriss | 359.3×209.5×5.5 mm |
| Formstil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Oberfläche | Glare (Haze 0%) |
| Helligkeit | 220 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193160% |
| Reaktionszeit | 3/5 (Typ.)(Tr/Td) |
| Blickwinkel | 45/45/20/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NBPC |
| CLAA150PB03 | CPT | 15.0 | 1400×1050 |
| CLAA150XA03 | CPT | 15.0 | 1024×768 |
| CLAA150XP01Q | CPT | 15.0 | 1024×768 |
| CLAA150XP06CW | CPT | 15.0 | 1024×768 |
| CLAA154WB08A | CPT | 15.4 | 1280×800 |
| CLAA156WA01A | CPT | 15.6 | 1366×768 |
| CLAA156WA07A | CPT | 15.6 | 1366×768 |
| CLAA156WA11A | CPT | 15.6 | 1366×768 |
| CLAA156WA12 | CPT | 15.6 | 1366×768 |
| CLAA156WB11A | CPT | 15.6 | 1366×768 |
| B121EW03 V7 | AUO | 12.1 | 1280×800 |
| B140HAN01.3 | AUO | 14.0 | 1920×1080 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| HSD140PNW1-B00 | HannStar | 14.0 | 1600×900 |
| LP140WH2-TLE3 | LG Display | 14.0 | 1366×768 |
| LP150X08-B3 | LG Display | 15.0 | 1024×768 |
| LTD121EC5V | TOSHIBA | 12.1 | 1024×768 |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT24-P01 | Samsung | 15.6 | 1366×768 |
| N133HSE-EA3 | Innolux | 13.3 | 1920×1080 |
