| Artikelnummer | B140HAN01.3 |
| Marke | AUO |
| Größe | 14.0 |
| Anwendung | NBPC |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 700:1 |
| Farben | 16.2M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | eDP |
| Panel-Marke | AUO |
| Panel-Modell | B140HAN01.3 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 14.0 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | AHVA, Normally Black, Transmissive |
| aktiver Bereich | 309.14×173.89 mm |
| Umriss | 320.4×205.6×3 mm |
| Formstil | Slim (PCBA Flat, Depth ≤3.2mm) |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 700:1 (Typ.) |
| Farben anzeigen | 16.2M (6-bit + FRC), CIE193172% |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | eDP (2 Lanes), 30 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NBPC |
| B140HAN01.0 | AUO | 14.0 | 1920×1080 |
| B140HAN01.1 | AUO | 14.0 | 1920×1080 |
| B140HAN01.2 | AUO | 14.0 | 1920×1080 |
| B140HAN01.3 | AUO | 14.0 | 1920×1080 |
| B140HAN01.8 | AUO | 14.0 | 1920×1080 |
| B140HAT02.0 | AUO | 14.0 | 1920×1080 |
| B140HTN01.1 | AUO | 14.0 | 1920×1080 |
| B140HTN01.3 | AUO | 14.0 | 1920×1080 |
| HB140WX1-501 | BOE | 14.0 | 1366×768 |
| LTN140AT02-B01 | Samsung | 14.0 | 1366×768 |
| B140HTN01.1 | AUO | 14.0 | 1920×1080 |
| LP140WH2-TLM1 | LG Display | 14.0 | 1366×768 |
| LP154WX7-TLB1 | LG Display | 15.4 | 1280×800 |
| LTD133EWDD | TOSHIBA | 13.3 | 1280×800 |
| LTM11C307S | TOSHIBA | 11.3 | 1024×768 |
| LTN133AT17-H01 | Samsung | 13.3 | 1366×768 |
| LTN156AT17-103 | Samsung | 15.6 | 1366×768 |
| LTN170WU-L01 | Samsung | 17.0 | 1920×1200 |
| LTN184KT01-J01 | Samsung | 18.4 | 1680×945 |
| N140FGE-L31 | Innolux | 14.0 | 1600×900 |
