| Artikelnummer | BP070WS1-400 |
| Marke | BOE |
| Größe | 7.0 |
| Anwendung | PAD |
| Auflösung | 1024×600 |
| Komposition | LCM |
| Helligkeit | 350 |
| CR | 900:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | BOE |
| Panel-Modell | BP070WS1-400 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 7.0 inch |
| Auflösung | 1024(RGB)×600 , WSVGA |
| Anzeigemodus | ADS, Normally Black, Transmissive |
| aktiver Bereich | 153.6×90 mm |
| Umriss | 162.8×102.9×4.2 mm |
| Oberfläche | Glare (Haze 0%), Hard coating (3H) |
| Helligkeit | 350 cd/m² (Typ.) |
| Kontrastverhältnis | 900:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Hi-FRC), CIE193152% |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 5S4PWLEDEmbedded (LED Driver) |
| Signalschnittstelle | MIPI (4 data lanes), 31 pins |
| Eingangsspannung | 3.7V (Typ.) |
| Anwendung | PAD |
