Artikelnummer | B133HAB01.0 HW1A |
Marke | AUO |
Größe | 13.3 |
Anwendung | Laptop |
Auflösung | 1920×1080 |
Komposition | a-Si TFT-LCD, Assemb |
Helligkeit | |
CR | 800:1 |
Farben | 262K |
Hintergrundbeleuchtung | WLED |
Schnittstelle | eDP |
Marke | AUO |
Modell | B133HAB01.0 HW1A (AUO102D) |
diagonale Größe | 13.3 inch |
Typ | a-Si TFT-LCD, Assembly |
Pixelformat | 1920(RGB)×1080 [FHD] 166PPI |
Aufbau | RGB Vertical Stripe |
aktiver Bereich | 293.472(H)×165.078(V) mm |
Umriss dunkel. | 317(H)×208(V) ×4.2(D) mm |
Lünettenbereich | - |
Behandlung | Anti-Scatter, Hard coating (7H) |
Leuchtdichte | 220 cd/m² (Typ.) |
Kontrastverhältnis | 800:1 (Typ.) (TM) |
Blickrichtung | Symmetry |
Reaktionszeit | 25 (Typ.)(Tr+Td) |
Blickwinkel | 85/85/85/85 (Typ.)(CR≥10) |
Betriebsart | AHVA, Normally Black, Transmissive |
Unterstützungsfarbe | 262K 45% NTSC |
Lichtquelle | WLED , 15K hours , With LED Driver |
Formstil | - |
designed für | Laptop |
Bildrate | 60Hz |
Touch-Panel | On-Cell Touch |
Oberflächentyp | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
Stromversorgung | 3.3V (Typ.) |
Umfeld | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
