| Artikelnummer | B116XW05 V004 |
| Marke | AUO |
| Größe | 11.6 |
| Anwendung | NOPC |
| Auflösung | 1366×768 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 700:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | eDP |
| Panel-Marke | AUO |
| Panel-Modell | B116XW05 V004 |
| Plattentyp | a-Si TFT-LCD , CELL |
| Panelgröße | 11.6 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 256.125×144 mm |
| Umriss | 289.34×155.9 mm |
| Oberfläche | Glare (Haze 0%), Hard coating (3H) |
| Glastiefe | 0.30+0.30 mm |
| Durchlässigkeit | 5.3% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 700:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193145% |
| Reaktionszeit | 16 (Typ.)(Tr+Td) |
| Blickwinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | eDP (1 Lane), 30 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NOPC |
