| Artikelnummer | B116HAN03.1 |
| Marke | AUO |
| Größe | 11.6 |
| Anwendung | PAD |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | 800:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | eDP |
| Panel-Marke | AUO |
| Panel-Modell | B116HAN03.1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 11.6 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | AHVA, Normally Black, Transmissive |
| aktiver Bereich | 256.32×144.18 mm |
| Umriss | 270.37×159.79×4.9 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193152% |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | eDP (2 Lanes), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PAD |
| B116HAN03.1 | AUO | 11.6 | 1920×1080 |
| B116HAT03.1 | AUO | 11.6 | 1920×1080 |
| B116XAN03.0 HW3A | AUO | 11.6 | 1366×768 |
| B116XTT01.0 | AUO | 11.6 | 1366×768 |
| B116XW05 V001 | AUO | 11.6 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| N116B6-L02 | Innolux | 11.6 | 1366×768 |
| N116B6-L04 | Innolux | 11.6 | 1366×768 |
| N116BGE-L41 | Innolux | 11.6 | 1366×768 |
| NT116WHM-N21 | BOE | 11.6 | 1366×768 |
| B101XAN02.0 | AUO | 10.1 | 1366×768 |
| CLAA101FP05 | CPT | 10.1 | 1920×1200 |
| HE070IA-04F | Innolux | 7.0 | 800×1280 |
| HE070IA-04M | Innolux | 7.0 | 800×1280 |
| HT10X21-311 | HYDIS | 10.4 | 1024×768 |
| LP101WH4-SLA6 | LG Display | 10.1 | 1366×768 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| LT121DKXBF00 | TOSHIBA | 12.1 | 1280×800 |
| N070ICE-G02 Rev.A2 | Innolux | 7.0 | 800×1280 |
| N101ICE-G62 | Innolux | 10.1 | 1280×800 |
