| Artikelnummer | AT101WSM-NW0-3800(3900) |
| Marke | BOE |
| Größe | 10.1 |
| Anwendung | CNS |
| Auflösung | 1024×600 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 600:1 |
| Farben | 262K/16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | BOE |
| Panel-Modell | AT101WSM-NW0-3800(3900) |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 10.1 inch |
| Auflösung | 1024(RGB)×600 , WSVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 222.72×125.28 mm |
| Umriss | 235×143×4.8 mm |
| Oberfläche | Antiglare (Haze 25%) |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Typ.) |
| Farben anzeigen | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| Reaktionszeit | 25 (Typ.)(Tr+Tf) |
| Blickwinkel | 80/80/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 3S7PWLEDWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6/8-bit), 60 pins |
| Eingangsspannung | 3.3/9.6V (Typ.)(VDD/AVDD) |
| Anwendung | CNS |
