| Artikelnummer | AM-1024600L2HMQW-T01H |
| Marke | AMPIRE |
| Größe | 10.1 |
| Anwendung | Industrial |
| Auflösung | 1024×600 |
| Komposition | a-Si TFT-LCD, LCM |
| Helligkeit | |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Marke | AMPIRE |
| Modell | AM-1024600L2HMQW-T01H |
| diagonale Größe | 10.1 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixelformat | 1024(RGB)×600 [WSVGA] 117PPI |
| Aufbau | RGB Vertical Stripe |
| aktiver Bereich | 222.72(H)×125.28(V) mm |
| Umriss dunkel. | 235(H)×145.8(V) ×9.8(D) mm |
| Lünettenbereich | 225.92(H)×128.48(V) mm |
| Behandlung | - |
| Leuchtdichte | 800 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) (TM) |
| Blickrichtung | - |
| Reaktionszeit | 4/12 (Typ.)(Tr/Td) |
| Blickwinkel | 70/70/70/50 (Typ.)(CR≥10) |
| Betriebsart | TN, Normally White, Transmissive |
| Unterstützungsfarbe | 262K 47% NTSC |
| Lichtquelle | WLED [6S6P] , 50K hours , With LED Driver |
| Gewicht | TBD |
| designed für | Industrial |
| Bildrate | 60Hz |
| Touch-Panel | 4-wire Resistive Touch |
| Oberflächentyp | LVDS (1 ch, 6-bit) , 30 pins Connector |
| Stromversorgung | 3.3V (Typ.) |
| Umfeld | Operating Temperature: -5 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
