| Artikelnummer | AA084XE11 |
| Marke | Mitsubishi |
| Größe | 8.4 |
| Anwendung | IA |
| Auflösung | 1024×768 |
| Komposition | LCM |
| Helligkeit | 1000 |
| CR | 600:1 |
| Farben | 262K/16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | Mitsubishi |
| Panel-Modell | AA084XE11 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 8.4 inch |
| Auflösung | 1024(RGB)×768 , XGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 170.496×127.872 mm |
| Umriss | 199.5×149 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 1000 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Typ.) |
| Farben anzeigen | 262K/16.7M (6-bit / 8-bit), CIE193140% |
| Reaktionszeit | 4/12 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 2 stringsWLEDWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6/8-bit), 20 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
| AA084SA01 | Mitsubishi | 8.4 | 800×600 |
| AA084SC01 | Mitsubishi | 8.4 | 800×600 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AA084VB01 | Mitsubishi | 8.4 | 640×480 |
| AA084VC03 | Mitsubishi | 8.4 | 640×480 |
| AA084VG01 | Mitsubishi | 8.4 | 640×480 |
| AA084XA03 | Mitsubishi | 8.4 | 1024×768 |
| AA084XB01 | Mitsubishi | 8.4 | 1024×768 |
| AA084XB11 | Mitsubishi | 8.4 | 1024×768 |
| AA084XE11 | Mitsubishi | 8.4 | 1024×768 |
| AC150XA01 | Mitsubishi | 15.0 | 1024×768 |
| DLC1210BBG | Other | 12.1 | 800×600 |
| ET035009DH6 | EDT | 3.5 | 320×240 |
| F-51430NFU-FW-AA | Kyocera | 9.4 | 640×480 |
| G104SN03 V4 | AUO | 10.4 | 800×600 |
| G150XTN01.1 | AUO | 15.0 | 1024×768 |
| G170EG01 V1 | AUO | 17.0 | 1280×1024 |
| LM240WU9-SLA1 | LG Display | 24.0 | 1920×1200 |
| LQ150X1LG71 | SHARP | 15.0 | 1024×768 |
| UG-2864HLBEG01 | WiseChip | 0.96 | 128×64 |
