| Artikelnummer | AA043MA01 |
| Marke | Mitsubishi |
| Größe | 4.3 |
| Anwendung | IA |
| Auflösung | 800×480 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 400:1 |
| Farben | 262K/16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | Mitsubishi |
| Panel-Modell | AA043MA01 1 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 4.3 inch |
| Auflösung | 800(RGB)×480 , WVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 93×55.8 mm |
| Umriss | 103×67.5×5.8 mm |
| Oberfläche | Clear, Hard coating (2H) |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 400:1 (Typ.) |
| Farben anzeigen | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| Reaktionszeit | 5/20 (Typ.)(Tr/Td) |
| Blickwinkel | 65/65/65/45 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 2 stringsWLEDWithout Driver |
| Signalschnittstelle | CMOS (1 ch, 6/8-bit), 45 pins |
| Eingangsspannung | 3.3V (Typ.)(VCC) |
| Anwendung | IA |
