| Artikelnummer | V500HJ1-L01 |
| Marke | Innolux |
| Größe | 50 |
| Anwendung | LCTV |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 350 |
| CR | 4000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | CHIMEI INNOLUX |
| Panel-Modell | V500HJ1-L01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 50 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | Super MVA, Normally Black, Transmissive |
| aktiver Bereich | 1095.84×616.41 mm |
| Umriss | 1142.84×663.41 mm |
| Oberfläche | Antiglare (Haze 3.5%), Hard coating (3H) |
| Helligkeit | 350 cd/m² (Typ.) |
| Kontrastverhältnis | 4000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 8 (Typ.)(G to G) |
| Blickwinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | CCFLEmbedded (Balance board) |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 51 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
