| Artikelnummer | V236BJ1-P02 |
| Marke | Innolux |
| Größe | 23.6 |
| Anwendung | LCTV |
| Auflösung | 1366×768 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 3000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | LVDS |
| Panel-Marke | CHIMEI INNOLUX |
| Panel-Modell | V236BJ1-P02 |
| Plattentyp | a-Si TFT-LCD , CELL |
| Panelgröße | 23.6 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | MVA, Normally Black, Transmissive |
| aktiver Bereich | 521.471×293.184 mm |
| Umriss | 535.06×306.34 mm |
| Oberfläche | Antiglare (Haze 1%), Hard coating (3H) |
| Glastiefe | 0.50+0.50 mm |
| Durchlässigkeit | 5.4% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 3000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 8.5 (Typ.)(G to G) |
| Blickwinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
