| Artikelnummer | TD070WGCB1 |
| Marke | TPO |
| Größe | 7.0 |
| Anwendung | CNS |
| Auflösung | 854×480 |
| Komposition | LCM |
| Helligkeit | 420 |
| CR | 150:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | TTL |
| Panel-Marke | Toppoly |
| Panel-Modell | TD070WGCB1 |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 7.0 inch |
| Auflösung | 854(RGB)×480 , FWVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 155×87.12 mm |
| Umriss | 166.4×106.3×8.9 mm |
| Oberfläche | |
| Helligkeit | 420 cd/m² (Typ.) |
| Kontrastverhältnis | 150:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 7/18 (Typ.)(Tr/Td) |
| Blickwinkel | 75/75/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 2 pcsCCFLWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 40 pins |
| Eingangsspannung | 3.3V (Typ.)(VDD) |
| Anwendung | CNS |
