| Artikelnummer | T420HVN06.1 |
| Marke | AUO |
| Größe | 42 |
| Anwendung | LCTV |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 350 |
| CR | 3000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | AUO |
| Panel-Modell | T420HVN06.1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 42 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | AMVA3, Normally Black, Transmissive |
| aktiver Bereich | 930.24×523.26 mm |
| Umriss | 952.2×547×27.3 mm |
| Oberfläche | Antiglare (Haze 2%), Hard coating (3H) |
| Helligkeit | 350 cd/m² (Typ.) |
| Kontrastverhältnis | 3000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 6.5 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 51 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
| T420HB01 V1 | AUO | 42 | 1920×1080 |
| T420HVN01.1 | AUO | 42 | 1920×1080 |
| T420HVN02.0 | AUO | 42 | 1920×1080 |
| T420HVN02.1 | AUO | 42 | 1920×1080 |
| T420HVN04.5 CELL | AUO | 42 | 1920×1080 |
| T420HW01 V2 | AUO | 42 | 1920×1080 |
| T420HW02 V0 | AUO | 42 | 1920×1080 |
| T420HW04 V3 | AUO | 42 | 1920×1080 |
| T420HW05 V3 | AUO | 42 | 1920×1080 |
| T420HW06 V0 | AUO | 42 | 1920×1080 |
| LC260WX2-SL01 | LG Display | 26.0 | 1366×768 |
| LC320DUH-FGP2 | LG Display | 31.5 | 1920×1080 |
| LC320EXN-FEP1 | LG Display | 31.5 | 1366×768 |
| LC370WUN-SBD1 | LG Display | 37 | 1920×1080 |
| LC470WUE-SEP1 | LG Display | 47 | 1920×1080 |
| LTA400HM23 | Samsung | 40 | 1920×1080 |
| ST5461B03-1 | CSOT | 55 | 1920×1080 |
| T315HW07 VC | AUO | 31.5 | 1920×1080 |
| T650HVN07.0 | AUO | 65 | 1920×1080 |
| V315B5-LE2 | Innolux | 31.5 | 1366×768 |
