| Artikelnummer | S50HW-YB06 |
| Marke | Samsung |
| Größe | 50 |
| Anwendung | LCTV |
| Auflösung | 1365×768 |
| Komposition | PDP |
| Helligkeit | 630 |
| CR | 5000:1 |
| Farben | 1.07B |
| Hintergrundbeleuchtung | self |
| Schnittstelle | LVDS |
| Panel-Marke | SAMSUNG SDI |
| Panel-Modell | S50HW-YB06 |
| Plattentyp | PDP , PDP |
| Panelgröße | 50 inch |
| Auflösung | 1365(RGB)×768 , WXGA |
| aktiver Bereich | 1105.65×622.08 mm |
| Umriss | 1175.4×688 mm |
| Oberfläche | |
| Helligkeit | 630 cd/m² (Typ.) |
| Kontrastverhältnis | 5000 : 1 (Typ.) |
| Farben anzeigen | 1.07B (10-bit) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | LVDS (1 ch, 10-bit) + SPI, 30 pins |
| rohs: | |
| Anwendung | LCTV |
