| Artikelnummer | LTA520HB03-001 |
| Marke | Samsung |
| Größe | 52 |
| Anwendung | LCTV |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 2000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | SAMSUNG |
| Panel-Modell | LTA520HB03-001 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 52 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | S-PVA, Normally Black, Transmissive |
| aktiver Bereich | 1152×648 mm |
| Umriss | 1226×719.2 mm |
| Oberfläche | Antiglare (Haze 44%), Hard coating (3H) |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 2000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 10/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 24 pcsCCFLEmbedded (Inverter) |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 51 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
