| Artikelnummer | LTA080B441A |
| Marke | TOSHIBA |
| Größe | 8.0 |
| Anwendung | |
| Auflösung | 480×234 |
| Komposition | LCM |
| Helligkeit | 350 |
| CR | 300:1 |
| Farben | Full color |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Analog |
| Panel-Marke | Toshiba Matsushita |
| Panel-Modell | LTA080B441A |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 8.0 inch |
| Auflösung | 480(RGB)×234 |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 175.68×99.45 mm |
| Umriss | 187×113 mm |
| Oberfläche | Antiglare |
| Helligkeit | 350 cd/m² (Typ.) |
| Kontrastverhältnis | 300:1 (Typ.) |
| Farben anzeigen | Full color |
| Reaktionszeit | 11/22 (Typ.)(Tr/Td) |
| Blickwinkel | 60/60/30/60 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | TFT Specific Analog RGB, 30 pins |
| Eingangsspannung | 3.3/5.0/17/-13V (Typ.)(VDD/VEE/VGON/VSS) |
