| Artikelnummer | LQ133T1JW19 |
| Marke | SHARP |
| Größe | 13.3 |
| Anwendung | NBPC |
| Auflösung | 2560×1440 |
| Komposition | LCM |
| Helligkeit | 350 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | eDP |
| Panel-Marke | SHARP |
| Panel-Modell | LQ133T1JW19 |
| Plattentyp | IGZO TFT-LCD , LCM |
| Panelgröße | 13.3 inch |
| Auflösung | 2560(RGB)×1440 , Quad-HD |
| Anzeigemodus | Normally Black, Transmissive |
| aktiver Bereich | 293.76×165.24 mm |
| Umriss | 304.98×178.2×2.6 mm |
| Formstil | Slim (PCBA Flat, Depth ≤3.2mm) |
| Oberfläche | Antiglare (Haze 42%) |
| Helligkeit | 350 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | eDP (4 Lanes), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NBPC |
