| Artikelnummer | LP156WH1-TLA1 |
| Marke | LG Display |
| Größe | 15.6 |
| Anwendung | NBPC |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 220 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | LG Display |
| Panel-Modell | LP156WH1-TLA1 10 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.6 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 344.232×193.536 mm |
| Umriss | 359.3×209.5×6.5 mm |
| Formstil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Oberfläche | Glare (Haze 0%), Hard coating (3H) |
| Helligkeit | 220 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193160% |
| Reaktionszeit | 16 (Typ.)(Tr+Td) |
| Blickwinkel | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 30 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NBPC |
| LP156WD1-TLA1 | LG Display | 15.6 | 1600×900 |
| LP156WF1-TLB2 | LG Display | 15.6 | 1920×1080 |
| LP156WF4-SPC1 | LG Display | 15.6 | 1920×1080 |
| LP156WH2-TLA1 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLBA | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLE1 | LG Display | 15.6 | 1366×768 |
| LP156WH3-TLC1 | LG Display | 15.6 | 1366×768 |
| LP156WH3-TLE1 | LG Display | 15.6 | 1366×768 |
| LP156WH4-TPA1 | LG Display | 15.6 | 1366×768 |
| LP156WHA-SLA2 | LG Display | 15.6 | 1366×768 |
| B140RW02 V1 | AUO | 14.0 | 1600×900 |
| B170PW03 V0 | AUO | 17.0 | 1440×900 |
| HT121X01-101 | HYDIS | 12.1 | 1024×768 |
| LP171WU1-TLA3 | LG Display | 17.1 | 1920×1200 |
| LP171WU5-TLB1 | LG Display | 17.1 | 1920×1200 |
| LQ133K1LA04 | SHARP | 13.3 | 1280×800 |
| LTD133EWZX | TOSHIBA | 13.3 | 1280×800 |
| LTN154BT05-001 | Samsung | 15.4 | 1440×900 |
| LTN156AT35-W01 | Samsung | 15.6 | 1366×768 |
| LTN170X2-L02 | Samsung | 17.0 | 1440×900 |
