| Artikelnummer | LMG9980ZWCC-01 |
| Marke | KOE |
| Größe | 12.1 |
| Anwendung | IA |
| Auflösung | 800×600 |
| Komposition | LCM |
| Helligkeit | 70 |
| CR | 30:1 |
| Farben | Color |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Parallel Data |
| Panel-Marke | HITACHI |
| Panel-Modell | LMG9980ZWCC-01 |
| Plattentyp | CSTN-LCD , LCM |
| Panelgröße | 12.1 inch |
| Auflösung | 800(RGB)×600 , SVGA |
| Anzeigemodus | STN, Normally Black |
| aktiver Bereich | 246×184.5 mm |
| Umriss | 275×202.5 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 70 cd/m² (Typ.) |
| Kontrastverhältnis | 30 : 1 (Typ.) |
| Farben anzeigen | Color |
| Reaktionszeit | 170/130 (Typ.)(Tr/Td) |
| Blickwinkel | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| Frequenz | 120Hz |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | Parallel Data (8-bit), 41 pins |
| Eingangsspannung | 3.3/5.0V (Typ.)(VDD) |
| Anwendung | IA |
