| Artikelnummer | LD420EUB-SDA1 |
| Marke | LG Display |
| Größe | 42 |
| Anwendung | PID |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 1300:1 |
| Farben | 16.7M/1.06B |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | LG Display |
| Panel-Modell | LD420EUB-SDA1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 42 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 930.24×523.26 mm |
| Umriss | 958.4×551.3×31.4 mm |
| Oberfläche | Antiglare (Haze 10%), Hard coating (3H) |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 1300:1 (Typ.) |
| Farben anzeigen | 16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172% |
| Reaktionszeit | 12 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (2 ch, 8/10-bit), 51 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | PID |
| BRS420H2 | 42 | 1920×1080 | |
| LC420DUE-SFR1 | LG Display | 42 | 1920×1080 |
| LC420DUH-FGA2 | LG Display | 42 | 1920×1080 |
| LC420DUN-SEU3 | LG Display | 42 | 1920×1080 |
| LC420EUD-SEF2 | LG Display | 42 | 1920×1080 |
| LC420EUN-PFF1 | LG Display | 42 | 1920×1080 |
| LD420EUB-SDA1 | LG Display | 42 | 1920×1080 |
| LD420EUN-UHB1 | LG Display | 42 | 1920×1080 |
| LD420EUP-SEA1 | LG Display | 42 | 1920×1080 |
| LD420EUP-SEB1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SBA1 | LG Display | 42 | 1920×1080 |
| LD470DUE-SFR1 | LG Display | 47 | 1920×1080 |
| LD550EUE-FHB1 | LG Display | 55 | 1920×1080 |
| LD720DUQ-SCA1 | LG Display | 72 | 1920×1080 |
| LTI370LN01 | Samsung | 37 | 1920×540 |
| LTI400HA08-V | Samsung | 40 | 1920×1080 |
| LTI460HN03 | Samsung | 46 | 1920×1080 |
| LTI550FN01 | Samsung | 55 | 3840×2160 |
| ND168TXP01 | 16.8 | 1366×378 | |
| RX366HDL-C07 | ROGIN | 36.6 | 1920×290 |
